FREEDEO FD-S20 Passive 3D Cinema System

Name: FREEDEO FD-S20 Passive 3D Cinema System
Brand: FREEDEO
SKU: FD-S20-3D-CINEMA

The FREEDEO FD-S20 is a polarized passive 3D cinema system designed for use with a single digital cinema projector. The system provides an efficient solution for cinema 3D projection with automatic 2D/3D switching and motorized polarizer positioning. The FD-S20 can be installed directly in front of a digital cinema projector using the supplied mounting bracket. When a 3D signal is detected, the polarizer automatically moves into the projector light path, and it moves back to the standby position during 2D playback or when the system is idle. The system is designed for clear and bright 3D projection and supports TMS-based operation. It includes a polarizer, motorized bracket, synchronization cable and optional power converter. The system also provides L/R switching for correcting left/right eye polarity when required.

Request Quote

Specifications

System Type: Passive Polarized 3D Cinema System

Application: Digital Cinema Projection with Single Projector

3D Switching: Automatic 2D/3D switching

Light Efficiency: 16% ±1%

Contrast: >100:1

Crosstalk: <2%

Response Time: <150 μs

Supported Frame Rates: 24 fps, 48 fps and 60 fps

Sync Input: 3D Interface, 15-pin

Power Consumption: ≤2.5 W

Polarizer Dimensions: Approx. 234 × 211 × 25 mm

Polarizer Weight: Approx. 1.3 kg

Cinema Matching: FREEDEO polarized 3D glasses or equivalent

Recommended Screen: Silver screen with gain ≥2.4

System Components: Polarizer, motorized bracket, manual/cabinet mounting components and sync cable

Control: TMS-compatible automatic 2D/3D operation

L/R Switching: Left/right eye polarity switching for 3D image correction

Operating Temperature: 0–50°C

Operating Humidity: <60% RH

Installation: Compatible mounting provisions for selected Barco S, C, Cx and B series digital projectors
